ViewMASTER™ Bi-Fold Door (bottom rolling)

Home » ViewMASTER™ Bi-Fold Door (bottom rolling)

Architectural Series | Series 412

For strength, beauty and whisper-quiet function, you can’t go past the ViewMaster bottom rolling bi-fold door!

  • The system supports 50mm thick heavy-duty Series 50 and 52 door framing and is so strong it can carry panels up to 3000mm high.
  • With stainless steel bearing rollers in a heavy-duty concealed sill track, they’re not just strong, they’re stunning and built to last.
  • Surelock™ adjustment system delivers precision and the perfect fit every time.
  • Choose from great lever and lock options to suit a wide variety of style and security applications and finishes.
  • Rollers and pivots under the door panels are covered with a flexible silicone flap. It doesn’t just hide the mechanism but also keeps dust and water away from the rollers so they always move easily.
  • Tested to resist 450Pa water, they’re suitable for any environment throughout Australia. They can also be fitted with Centor Eco Screen for a retractable and discreet barrier against creepy crawlies.
Maximum Panel Height*3000mm
Maximum Panel Width*1000mm
Maximum Glass Thickness≤ 28mm
SHGC Range0.14 - 0.59
Uw Range3.4 - 6.2

Compatible hardware

Elevate Commercial handles and locks which suit the ViewMASTER™ Bi-Fold Door (bottom rolling).
